50 MHz to 870 MHz High Dynamic Amplifier

50 MHz to 870 MHz High Dynamic Amplifier
Part # CMM6003-SC
Key features

❏50 MHz to 870 MHz Frequency Range
❏+41 dBm Output IP3
❏1.6 dB Noise Figure (@450 MHz)
❏17 dB Gain
❏22 dBm P1dB
❏SOT-89 SMT Package
❏Single Power Supply
❏+3V to +5V Voltage Rail


The CMM6003-SC is a high dynamic range amplifier designed for applications operating within the 50 MHz to 870 MHz frequency range. It is an ideal solution for transmit and receive functions where high linearity is required. The amplifier has the flexibility of being optimized for a number of wireless applications. The combination of gain flatness, bandwidth, low NF and high IP3 at the same bias point make it an ideal transmit or receive solution when used in intermediate frequency applications.
The CMM6003-SC is packaged in a low-cost, space efficient, surface mount SOT-89 package which provides excellent electrical stability and low thermal resistance. All devices are 100% RF (at 800 MHz) and DC tested.

Frequency (GHz) 0.05-0.9
P1dB (dBm) +22.0
Gain (dB) 17.0
Icc (mA) 150
Output IP3 (dBm) +41.0
Voltage (V) +3.0 to +5.0
NF (dB) 1.6
Package () -SC (SOT-89)
Markets () I / S / P / D
